Part Number | 74HC237D,653 |
---|---|
Manufacturer | Nexperia |
Quantity in stock | 577890 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Latch Decoder Demultiplexer Single 3-to-8 16-Pin SO T R |
Category | Logic & Timing IC |
Family | Logic ICs |
ROHS Compliant | Yes |
MSL Level | 74HC237D,653 |
Datasheet download | ![]() |
Part Number | 74HC237D,653 |
---|---|
Number of Elements per Chip | 1 |
Maximum Operating Supply Voltage | 6 V |
Maximum Quiescent Current | 0.008 mA |
Polarity | Non-Inverting |
Logic Family | HC |
Typical Operating Supply Voltage | 5 V |
Propagation Delay Test Condition | 50 pF |
Demultiplexing Capability | 1-of-8 |
Maximum Low Level Output Current | 5.2 mA |
Fabrication Technology | CMOS |
Minimum Operating Supply Voltage | 2 V |
Number of Element Outputs | 8 |
Logic Function | Latch/Decoder/Demultiplexer |
Number of Element Inputs | 3 |
Maximum High Level Output Current | -5.2 mA |
Number of Output Enables per Element | 2 |
Number of Input Enables per Element | 1 |
Pin Count | 16 |
Max Processing Temp | 260 |
Rad Hard | No |
Mounting | Surface Mount |
MSL Level | 1 |
Lead Finish | Gold |
Product Dimensions | 10 x 4 x 1.45 mm |
Operating Temperature | -40 to 125 °C |
Supplier Package | SO |
Maximum Propagation Delay Time @ Maximum CL | 160@2V|[email protected]|27@6V ns |
Package | 16SO |
Replacement Part Number | PART-74HC237D,653 |
Weight | Contact us |
Country of Origin | - |
