ULN2803ADW Texas Instruments

ULN2803ADW Images

Please contact us for more photos of ULN2803ADW

Part Number ULN2803ADW
Manufacturer Texas Instruments
Quantity in stock 370420 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Trans Darlington NPN 50V 0.5A 18-Pin SOIC Tube
Category Discrete Semiconductor
Family Bipolar Transistor
ROHS Compliant Yes
MSL Level ULN2803ADW
Datasheet download ULN2803ADW.pdf
Request Quotation for ULN2803ADW

ULN2803ADW Specifications

Part Number ULN2803ADW
Maximum Collector Emitter Voltage 50 V
Configuration Octal Common Emitter
Peak DC Collector Current 0.5 A
Supplier Package SOIC
Type NPN
Product Dimensions 11.62 x 7.52 x 2.35 mm
MSL Level 2
Pin Count 18
Rad Hard No
Max Processing Temp 260
Maximum Collector Emitter Saturation Voltage 1.1@250uA@100mA|1.3@350uA@200mA|1.6@500uA@350mA V
Mounting Surface Mount
Lead Finish Gold
Package 18SOIC
Replacement Part Number PART-ULN2803ADW
Weight Contact us
Country of Origin -
