Please contact us for more photos of NCP1288BD65R2G
| Part Number | NCP1288BD65R2G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 386420 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Current Mode PWM Controller -0.3V to 20V 800mA 7-Pin SOIC T R |
| Category | Power Management IC |
| Family | PWM Controllers |
| ROHS Compliant | Yes |
| MSL Level | NCP1288BD65R2G |
| Datasheet download |  NCP1288BD65R2G.pdf |
| Part Number | NCP1288BD65R2G |
|---|---|
| Switching Frequency | 65 kHz |
| Output Current | 800 mA |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Product Dimensions | 5 x 4 x 1.5 mm |
| Pin Count | 7 |
| Output Voltage | -0.3 to 20 V |
| Fall Time | 22 ns |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Maximum Duty Cycle | 80 % |
| Adjustable Output | Yes |
| Rise Time | 22 ns |
| On/Off Pin | No |
| Number of PWM Outputs | 1 |
| Operating Temperature | -40 to 150 °C |
| MSL Level | 1 |
| Supplier Package | SOIC |
| Package | 7SOIC |
| Replacement Part Number | PART-NCP1288BD65R2G |
| Weight | Contact us |
| Country of Origin | - |
