Please contact us for more photos of ICE3AR2280VJZ
| Part Number | ICE3AR2280VJZ |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 242380 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Current Mode PWM Controller IC for SMPS 800V 7-Pin DIP Tube |
| Category | Power Management IC |
| Family | PWM Controllers |
| ROHS Compliant | Yes |
| MSL Level | ICE3AR2280VJZ |
| Datasheet download |  ICE3AR2280VJZ.pdf |
| Part Number | ICE3AR2280VJZ |
|---|---|
| Mounting | Through Hole |
| Maximum Duty Cycle | 80 % |
| Rad Hard | No |
| On/Off Pin | No |
| Product Dimensions | 9.77(Max) x 6.6(Max) x 4.19(Max) |
| Adjustable Output | No |
| Number of PWM Outputs | 1 |
| Switching Frequency | 16 to 22 kHz |
| Supplier Package | DIP |
| Max Processing Temp | 260 |
| Lead Finish | Tin |
| Rise Time | 30 ns |
| Pin Count | 7 |
| Topology | Flyback |
| Operating Temperature | -40 to 130 °C |
| Fall Time | 30 ns |
| Operating Supply Voltage | 10.5 to 25 V |
| Package | 7DIP |
| Replacement Part Number | PART-ICE3AR2280VJZ |
| Weight | Contact us |
| Country of Origin | - |
