Part Number | TJA1055T 3 1J |
---|---|
Manufacturer | NXP |
Quantity in stock | 607590 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | CAN 125KBd Sleep Standby 5.25V 14-Pin SOIC |
Category | Communication |
Family | LAN |
ROHS Compliant | Yes |
MSL Level | TJA1055T 3 1J |
Datasheet download | ![]() |
Part Number | TJA1055T 3 1J |
---|---|
Maximum Single Supply Voltage | 5.25 V |
Category | Transceiver |
Maximum Data Rate | 125 Kbps |
Rad Hard | No |
Minimum Single Supply Voltage | 4.75 V |
Supplier Package | SOIC |
Operating Temperature | -40 to 150 °C |
Mounting | Surface Mount |
Product Dimensions | 8.75(Max) x 4(Max) x 1.45(Max) |
MSL Level | 3 |
Pin Count | 14 |
Screening Level | Automotive |
Number of Transceivers | 1 |
Maximum Supply Current | 21 mA |
Standard Supported | TJA1054|TJA1054A |
Power Down Mode | Sleep|Standby |
Package | 14SOIC |
Replacement Part Number | PART-TJA1055T 3 1J |
Weight | Contact us |
Country of Origin | - |
