Please contact us for more photos of 74LVC16245ADL,118
| Part Number | 74LVC16245ADL,118 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 736960 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Bus XCVR Dual 16-CH 3-ST 48-Pin SSOP T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | 74LVC16245ADL,118 |
| Datasheet download |  74LVC16245ADL,118.pdf |
| Part Number | 74LVC16245ADL,118 |
|---|---|
| Maximum Quiescent Current | 80 uA |
| Maximum High Level Output Current | -24 mA |
| Maximum Operating Supply Voltage | 3.6 V |
| Pin Count | 48 |
| Lead Finish | Gold |
| Number of Selection Inputs per Element | 0 |
| Supplier Package | SSOP |
| Number of Output Enables per Element | 1 Low |
| Typical Quiescent Current | 0.1 uA |
| Input Level | LVTTL |
| Product Dimensions | 16 x 7.6 x 2.35 mm |
| Number of Input Enables per Element | 0 |
| Minimum Operating Supply Voltage | 1.2 V |
| Output Level | LVTTL |
| Typical Operating Supply Voltage | 1.8|2.5|3.3 V |
| Logic Function | Bus Transceiver |
| Data Flow Direction | Bi-Directional |
| Number of Direction Control Inputs | 1 Low/High |
| Number of Channels per Chip | 16 |
| Rad Hard | No |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|[email protected] ns |
| Mounting | Surface Mount |
| Polarity | Non-Inverting |
| Max Processing Temp | 260 |
| Propagation Delay Test Condition | 50 pF |
| MSL Level | 1 |
| Tolerant I/Os | 5 V |
| Fabrication Technology | CMOS |
| Logic Family | LVC |
| Operating Temperature | -40 to 125 °C |
| Maximum Low Level Output Current | 24 mA |
| Bus Hold | No |
| Output Type | 3-State |
| Number of Elements per Chip | 2 |
| Package | 48SSOP |
| Replacement Part Number | PART-74LVC16245ADL,118 |
| Weight | Contact us |
| Country of Origin | - |
