SN74LVC1G125DBVR Texas Instruments

SN74LVC1G125DBVR Images

Please contact us for more photos of SN74LVC1G125DBVR

Part Number SN74LVC1G125DBVR
Manufacturer Texas Instruments
Quantity in stock 348830 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Buffer Line Driver 1-CH Non-Inverting 3-ST CMOS 5-Pin SOT-23 T R
Category Logic & Timing IC
Family Logic ICs
ROHS Compliant Yes
MSL Level SN74LVC1G125DBVR
Datasheet download SN74LVC1G125DBVR.pdf
Request Quotation for SN74LVC1G125DBVR

SN74LVC1G125DBVR Specifications

Part Number SN74LVC1G125DBVR
Product Dimensions 2.9 x 1.6 x 1.15 mm
Mounting Surface Mount
Maximum High Level Output Current -32 mA
Maximum Propagation Delay Time @ Maximum CL [email protected]|4@5V ns
Rad Hard No
Operating Temperature -40 to 85 °C
Max Processing Temp 260
Lead Finish Matte Tin
MSL Level 1
Number of Output Enables per Chip 1 Low
Maximum Quiescent Current 10 uA
Typical Operating Supply Voltage 1.8|2.5|3.3|5 V
Logic Family LVC
Output Type 3-State
Maximum Low Level Output Current 32 mA
Logic Function Buffer/Line Driver
Supplier Package SOT-23
Pin Count 5
Number of Channels per Chip 1
Number of Inputs per Chip 1
Number of Elements per Chip 1
Fabrication Technology CMOS
Bus Hold No
Number of Outputs per Chip 1
Number of Input Enables per Chip 0
Input Signal Type Single-Ended
Maximum Operating Supply Voltage 5.5 V
Polarity Non-Inverting
Propagation Delay Test Condition 50 pF
Screening Level Commercial
Tolerant I/Os 5 V
Package 5SOT-23
Replacement Part Number PART-SN74LVC1G125DBVR
Weight Contact us
Country of Origin -
