Please contact us for more photos of SN74LVC125APW
| Part Number | SN74LVC125APW |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 642640 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Buffer Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin TSSOP Tube |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | SN74LVC125APW |
| Datasheet download |  SN74LVC125APW.pdf |
| Part Number | SN74LVC125APW |
|---|---|
| Fabrication Technology | CMOS |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|[email protected] ns |
| Typical Operating Supply Voltage | 1.8|2.5|3.3 V |
| Input Signal Type | Single-Ended |
| Lead Finish | Gold |
| Operating Temperature | -40 to 125 °C |
| Tolerant I/Os | 5 V |
| Propagation Delay Test Condition | 50 pF |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Logic Family | LVC |
| Output Type | 3-State |
| Number of Elements per Chip | 4 |
| Maximum Quiescent Current | 1 uA |
| Number of Inputs per Chip | 4 |
| Minimum Operating Supply Voltage | 1.65 V |
| Polarity | Non-Inverting |
| Maximum Operating Supply Voltage | 3.6 V |
| MSL Level | 1 |
| Pin Count | 14 |
| Supplier Package | TSSOP |
| Logic Function | Buffer/Line Driver |
| Bus Hold | No |
| Maximum Low Level Output Current | 24 mA |
| Product Dimensions | 5.1 x 4.5 x 1.05 mm |
| Number of Output Enables per Chip | 4 Low |
| Number of Outputs per Chip | 4 |
| Mounting | Surface Mount |
| Number of Input Enables per Chip | 0 |
| Number of Channels per Chip | 4 |
| Maximum High Level Output Current | -24 mA |
| Package | 14TSSOP |
| Replacement Part Number | PART-SN74LVC125APW |
| Weight | Contact us |
| Country of Origin | - |
