Please contact us for more photos of 74LV244PW,112
| Part Number | 74LV244PW,112 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 231530 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Buffer Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin TSSOP Tube |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | 74LV244PW,112 |
| Datasheet download |  74LV244PW,112.pdf |
| Part Number | 74LV244PW,112 |
|---|---|
| Lead Finish | Gold |
| Maximum High Level Output Current | -16 mA |
| Maximum Quiescent Current | 160 uA |
| Number of Output Enables per Chip | 2 Low |
| Number of Input Enables per Chip | 0 |
| Pin Count | 20 |
| Minimum Operating Supply Voltage | 1 V |
| Logic Family | LV |
| Typical Operating Supply Voltage | 3.3 V |
| Number of Inputs per Chip | 8 |
| Maximum Low Level Output Current | 16 mA |
| Rad Hard | No |
| Number of Elements per Chip | 2 |
| Input Signal Type | Single-Ended |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|17@2V|[email protected]|[email protected] ns |
| Max Processing Temp | 260 |
| Propagation Delay Test Condition | 50 pF |
| Polarity | Non-Inverting |
| Maximum Operating Supply Voltage | 5.5 V |
| Number of Outputs per Chip | 8 |
| MSL Level | 1 |
| Tolerant I/Os | 5 V |
| Supplier Package | TSSOP |
| Product Dimensions | 6.6 x 4.5 x 0.95 mm |
| Fabrication Technology | CMOS |
| Logic Function | Buffer/Line Driver |
| Number of Channels per Chip | 8 |
| Operating Temperature | -40 to 125 °C |
| Bus Hold | No |
| Output Type | 3-State |
| Mounting | Surface Mount |
| Package | 20TSSOP |
| Replacement Part Number | PART-74LV244PW,112 |
| Weight | Contact us |
| Country of Origin | - |
