Please contact us for more photos of HSMG-C170
| Part Number | HSMG-C170 |
|---|---|
| Manufacturer | Broadcom |
| Quantity in stock | 603940 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | LED Uni-Color Green 570nm 2-Pin Chip LED T R |
| Category | Lighting |
| Family | LEDs |
| ROHS Compliant | Yes |
| MSL Level | HSMG-C170 |
| Datasheet download |  HSMG-C170.pdf |
| Part Number | HSMG-C170 |
|---|---|
| Dominant Wavelength | 572 nm |
| Supplier Package | Chip LED |
| Intensity | 15 mcd |
| LED Material | GaP |
| Maximum Forward Voltage per Color | 2.6 V |
| Maximum Forward Current | 20 mA |
| Type | Uni-Color |
| Number of LEDs | 1 |
| Lens Shape Type | Rectangular |
| Color | Green |
| Category | Chip LED |
| Lens Dimensions | 1.4x1.25x0.5 mm |
| Viewing Angle | 170 ° |
| Peak Wavelength | 570 nm |
| Max Processing Temp | 255 to 260 |
| Maximum Power Dissipation | 52 mW |
| Product Dimensions | 2 x 1.25 x 0.8 mm |
| MSL Level | 2a |
| Reverse Voltage | 5 V |
| Lens Appearance | Colorless Diffused |
| Mounting Orientation | Top Mount |
| Pin Count | 2 |
| Mounting | Surface Mount |
| Lead Finish | Gold |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Package | 2Chip LED |
| Replacement Part Number | PART-HSMG-C170 |
| Weight | Contact us |
| Country of Origin | - |
