HLMP-AL64-23KDD Broadcom

Please contact us for more photos of HLMP-AL64-23KDD

Part Number	HLMP-AL64-23KDD
Manufacturer	Broadcom
Quantity in stock	546520 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Amber 594nm 2-Pin T-1 3 4 Ammo
Category	Lighting
Family	HB LEDs
ROHS Compliant	Yes
MSL Level	HLMP-AL64-23KDD
Datasheet download	HLMP-AL64-23KDD.pdf

Request Quotation for HLMP-AL64-23KDD

HLMP-AL64-23KDD Specifications

Part Number	HLMP-AL64-23KDD
Product Dimensions	5.2 x 3.8 x 8.7 mm
Reverse Voltage	5 V
Supplier Package	T-1 3/4
Type	Uni-Color
Viewing Angle	70/30 °
Lens Dimensions	5.2x3.8x8.7 mm
Peak Wavelength	594 nm
Maximum Forward Current	50 mA
Max Processing Temp	260
Mounting	Through Hole
Pin Count	2
Maximum Forward Voltage per Color	2.4 V
Operating Temperature	-40 to 100 °C
Category	Standard LED
Rad Hard	No
Lens Appearance	Colored Diffused
Dominant Wavelength	590 nm
Lens Shape Type	Oval
Color	Amber
Mounting Orientation	Top Mount
Lead Finish	Matte Tin
Maximum Power Dissipation	120 mW
Number of LEDs	1
Package	2T-1 3/4
Replacement Part Number	PART-HLMP-AL64-23KDD
Weight	Contact us
Country of Origin	-
