ASMT-FG10-NFJ00 Broadcom

Please contact us for more photos of ASMT-FG10-NFJ00

Part Number	ASMT-FG10-NFJ00
Manufacturer	Broadcom
Quantity in stock	431400 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Green 525nm 6-Pin SMD T R
Category	Lighting
Family	LEDs
ROHS Compliant	Yes
MSL Level	ASMT-FG10-NFJ00
Datasheet download	ASMT-FG10-NFJ00.pdf

Request Quotation for ASMT-FG10-NFJ00

ASMT-FG10-NFJ00 Specifications

Part Number	ASMT-FG10-NFJ00
Product Dimensions	4.8 x 4.8 x 5.33 mm
Maximum Power Dissipation	80 mW
Lead Finish	Matte Tin
Rad Hard	No
Viewing Angle	11 °
Pin Count	6
Number of LEDs	1
Operating Temperature	-40 to 85 °C
Dominant Wavelength	530 nm
Mounting	Surface Mount
MSL Level	3
Maximum Forward Voltage per Color	3.9 V
Lens Shape Type	Circular
LED Material	InGaN
Peak Wavelength	525 nm
Lens Appearance	Colorless Non Diffused
Mounting Orientation	Top Mount
Max Processing Temp	260
Supplier Package	SMD
Maximum Forward Current	20 mA
Category	Chip LED
Color	Green
Type	Uni-Color
Intensity	56000 mcd
Reverse Voltage	5 V
Package	6SMD
Replacement Part Number	PART-ASMT-FG10-NFJ00
Weight	Contact us
Country of Origin	-
