Please contact us for more photos of SRP5030T-6R8M
| Part Number | SRP5030T-6R8M |
|---|---|
| Manufacturer | Bourns |
| Quantity in stock | 384070 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Shielded 6.8uH 20% 100KHz Powdered Iron 4.3A 2220 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | SRP5030T-6R8M |
| Datasheet download |  SRP5030T-6R8M.pdf |
| Part Number | SRP5030T-6R8M |
|---|---|
| Maximum DC Current | 2.75 A |
| Product Dimensions | 5.7 x 5.2 x 2.8 |
| Supplier Package | 2220 |
| Package/Case | 2220 |
| Lead Finish | Tin |
| Protection Style | Shielded |
| MSL Level | 1 |
| Minimum Quality Factor | |
| Impedance | |
| Maximum Self Resonant Frequency | |
| Core Material | Powdered Iron |
| Pin Count | 2 |
| Rad Hard | No |
| Maximum DC Resistance | 128 mOhm |
| Max Processing Temp | 260 |
| Tolerance | 20 % |
| Operating Temperature | -40 to 125 °C |
| Type | Power |
| Test Frequency | 100 kHz |
| Inductance | 10 uH |
| Product Depth | 5.2 mm |
| Product Height | 2.8 mm |
| Product Length | 5.7 mm |
| Replacement Part Number | PART-SRP5030T-6R8M |
| Weight | Contact us |
| Country of Origin | - |
