Please contact us for more photos of PM3604-15-RC
| Part Number | PM3604-15-RC |
|---|---|
| Manufacturer | Bourns |
| Quantity in stock | 427830 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Wirewound 15uH 60uH 20% Iron 2.2A 1.1A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | PM3604-15-RC |
| Datasheet download |  PM3604-15-RC.pdf |
| Part Number | PM3604-15-RC |
|---|---|
| Package/Case | 13.97 X 13.97 X 6.73 |
| Lead Finish | Tin/Silver/Copper |
| Technology | Wirewound |
| Rad Hard | No |
| Max Processing Temp | 245 |
| Tolerance | 20 % |
| MSL Level | 1 |
| Product Dimensions | 13.97 x 13.97 x 6.73 mm |
| Operating Temperature | -55 to 125 °C |
| Product Depth | 13.97 mm |
| Product Height | 6.73 mm |
| Product Length | 13.97 mm |
| Replacement Part Number | PART-PM3604-15-RC |
| Weight | Contact us |
| Country of Origin | - |
