Part Number | CR0603-FX-1302ELF |
---|---|
Manufacturer | Bourns |
Quantity in stock | 215060 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Res Thick Film 0603 13K Ohm 1% 1 10W \u00b1100ppm \u00b0C Molded SMD SMD Paper Tape on Plastic Reel |
Category | Resistor |
Family | Resistor Fixed Single-Surface Mount |
ROHS Compliant | Yes |
MSL Level | CR0603-FX-1302ELF |
Datasheet download | ![]() |
Part Number | CR0603-FX-1302ELF |
---|---|
Power Rating | 0.1 W |
Temperature Coefficient | ±100 ppm/°C |
Max Processing Temp | 260 |
Product Dimensions | 1.6 x 0.8 x 0.45 mm |
Rad Hard | No |
MSL Level | 1 |
Mounting | Surface Mount |
Tolerance | 1 % |
Lead Finish | Tin |
Resistance Value | 13 kOhm |
Case Size | 0603 |
Operating Temperature | -55 to 155 °C |
Case Style | Molded |
Product Depth | 0.8 mm |
Product Height | 0.45 mm |
Product Length | 1.6 mm |
Replacement Part Number | PART-CR0603-FX-1302ELF |
Weight | Contact us |
Country of Origin | - |
