Please contact us for more photos of CAT16-391J4LF
| Part Number | CAT16-391J4LF |
|---|---|
| Manufacturer | Bourns |
| Quantity in stock | 620110 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film Array 390 Ohm 5% ISOL Molded 8-Pin 1206 Concave SMD Paper T R |
| Category | Resistor |
| Family | Resistor Networks and Arrays |
| ROHS Compliant | Yes |
| MSL Level | CAT16-391J4LF |
| Datasheet download |  CAT16-391J4LF.pdf |
| Part Number | CAT16-391J4LF |
|---|---|
| Power Rating per Resistor | 1/16 W |
| Termination Style | Concave |
| Rad Hard | No |
| Tolerance | 5 % |
| Case Style | Molded |
| Max Processing Temp | 260 |
| Case Size | 1206 |
| Resistance Value | 390 Ohm |
| Technology | Thick Film |
| Mounting | Surface Mount |
| Terminal Pitch | 0.8 mm |
| Lead Finish | Tin |
| Product Dimensions | 3.2 x 1.55 x 0.5 mm |
| Operating Temperature | -55 to 125 °C |
| MSL Level | 1 |
| Product Depth | 1.55 mm |
| Product Height | 0.5 mm |
| Product Length | 3.2 mm |
| Replacement Part Number | PART-CAT16-391J4LF |
| Weight | Contact us |
| Country of Origin | - |
