Please contact us for more photos of 3361P-1-104GLF
| Part Number | 3361P-1-104GLF |
|---|---|
| Manufacturer | Bourns |
| Quantity in stock | 337450 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Cermet Trimmer 100K Ohm 10% 1 2W 1(Elec) 1(Mech)Turn 2.77mm (6.71 X 8.53 X 5.21mm) Gull Wing SMD Embossed T R |
| Category | Resistor |
| Family | Resistor Trimmers, Potentiometers and Rheostats |
| ROHS Compliant | Yes |
| MSL Level | 3361P-1-104GLF |
| Datasheet download |  3361P-1-104GLF.pdf |
| Part Number | 3361P-1-104GLF |
|---|---|
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Operating Temperature | -55 to 125 °C |
| MSL Level | 1 |
| Termination Style | Gull Wing |
| Shaft Diameter | 2.77 mm |
| Temperature Coefficient | ±100 ppm |
| Mounting | Surface Mount |
| Resistance Value | 100 kOhm |
| Technology | Cermet |
| Power Rating | 0.5 W |
| Product Dimensions | 6.71 x 8.53 x 5.21 mm |
| Tolerance | 10 % |
| Max Processing Temp | 260 |
| Product Depth | 8.53 mm |
| Product Height | 5.21 mm |
| Product Length | 6.71 mm |
| Replacement Part Number | PART-3361P-1-104GLF |
| Weight | Contact us |
| Country of Origin | - |
| Image | Part Number and Brand | Brief Description and PDF Datasheet |
|---|---|---|
|
Bourns | Res Cermet Trimmer 100K Ohm 10% 3 4W 15(Elec)Turn 2.36mm (20.57 X 4.83 X 6.35mm) Pin Thru-Hole Tube Download PDF datasheet for 3006P-1-104LF.pdf |
|
Panasonic | Res Cermet Trimmer 10K Ohm 25% 3 20W 1Turn (2.2 X 2.81 X 0.81mm) Foot Print SMD Carrier T R Download PDF datasheet for EVM2NSX80B14.pdf |
|
Bourns | Res Cermet Trimmer 5K Ohm 10% 1 2W 25(Elec)Turn 2.19mm (9.53 X 4.83 X 11.55mm) Pin Thru-Hole Tube Download PDF datasheet for 3296W-1-502LF.pdf |
|
Bourns | Res Cermet Trimmer 20K Ohm 10% 1 2W 1(Elec) 1(Mech)Turn 3.15mm (9.53 X 9.53 X 4.83mm) Pin Thru-Hole Tube Download PDF datasheet for 3386P-1-203LF.pdf |
|
Bourns | Res Cermet Trimmer 200K Ohm 10% 1 2W 25(Elec)Turn 2.19mm (9.53 X 4.83 X 11.55mm) Pin Thru-Hole Tube Download PDF datasheet for 3296Y-1-204LF.pdf |
|
Panasonic | Res Cermet Trimmer 5K Ohm 25% 3 20W 1Turn (3.1 X 3.75 X 1.4mm) Foot Print SMD Carrier T R Download PDF datasheet for EVM3VSX50B53.pdf |
|
Bourns | Res Cermet Trimmer 5K Ohm 10% 1 4W 12(Elec)Turn 1.78mm (6.71 X 4.5 X 8.26mm) Pin Thru-Hole Tube Download PDF datasheet for 3266W-1-502LF.pdf |
|
Bourns | Res Cermet Trimmer 20K Ohm 10% 1 4W 12(Elec)Turn 1.78mm (6.35 X 4.32 X 7.37mm) Pin Thru-Hole Tube Download PDF datasheet for 3262W-1-203LF.pdf |
|
Vishay | Res Cermet Trimmer 100 Ohm 10% 1 4W 11(Elec) 13(Mech)Turn 1.5mm (4.8 X 3.8 X 5.3mm) J-Hook SMD T R Download PDF datasheet for TSM4YJ101KR05....pdf |
|
Panasonic | Res Cermet Trimmer 500 Ohm 25% 3 20W 1Turn (2.2 X 2.81 X 0.81mm) Foot Print SMD Carrier T R Download PDF datasheet for EVM2NSX80B52.pdf |
