3224G-1-100E Bourns

3224G-1-100E Images

Please contact us for more photos of 3224G-1-100E

Part Number 3224G-1-100E
Manufacturer Bourns
Quantity in stock 781480 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Res Cermet Trimmer 10 Ohm 10% 1 4W 12(Elec)Turn 1.5mm (4.8 X 6 X 3.9mm) Gull Wing SMD Embossed T R
Category Resistor
Family Resistor Trimmers, Potentiometers and Rheostats
ROHS Compliant Yes
MSL Level 3224G-1-100E
Datasheet download 3224G-1-100E.pdf
Request Quotation for 3224G-1-100E

3224G-1-100E Specifications

Part Number 3224G-1-100E
Max Processing Temp 250
Operating Temperature -65 to 150 °C
Power Rating 0.25 W
Product Dimensions 4.8 x 6 x 3.9 mm
Technology Cermet
Tolerance 10 %
Shaft Diameter 1.5 mm
Resistance Value 10 Ohm
Rad Hard No
Mounting Surface Mount
Termination Style Gull Wing
MSL Level 1
Temperature Coefficient ±100 ppm
Lead Finish Tin
Product Depth 6 mm
Product Height 3.9 mm
Product Length 4.8 mm
Replacement Part Number PART-3224G-1-100E
Weight Contact us
Country of Origin -
