2200LL-101-H-RC Bourns

2200LL-101-H-RC Images

Please contact us for more photos of 2200LL-101-H-RC

Part Number 2200LL-101-H-RC
Manufacturer Bourns
Quantity in stock 694210 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind High Current Toroid 100uH 15% 1KHz 6.8A RDL
Category Inductor
Family Inductor Leaded
ROHS Compliant Yes
MSL Level 2200LL-101-H-RC
Datasheet download 2200LL-101-H-RC.pdf
Request Quotation for 2200LL-101-H-RC

2200LL-101-H-RC Specifications

Part Number 2200LL-101-H-RC
Lead Style Radial
Tolerance 15 %
Lead Finish Tin
Operating Temperature -55 to 125 °C
Product Dimensions 13.97 mm
Test Frequency 1 kHz
Technology Toroid
Rad Hard No
Package/Case 27.94 X 13.97
Type High Current
Product Diameter 27.94 mm
Product Height 13.97 mm
Replacement Part Number PART-2200LL-101-H-RC
Weight Contact us
Country of Origin -
