Please contact us for more photos of SR217A151JAR
| Part Number | SR217A151JAR |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 481110 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 150pF 500V C0G 5% Radial 5.08mm 125\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | SR217A151JAR |
| Datasheet download |  SR217A151JAR.pdf |
| Part Number | SR217A151JAR |
|---|---|
| Capacitance Value | 150 pF |
| Product Dimensions | 5.08 x 3.175 x 5.08 mm |
| Package/Case | 5.08(Max) X 3.175(Max) X 5.08(Max) |
| Lead Pitch For Radial | 5.08 mm |
| Seated Plane Height | 7.62 mm |
| Mounting | Through Hole |
| Wire Form | Inside Crimp Standoff |
| Case Style | Dipped |
| Voltage(DC) | 500 V |
| Rad Hard | No |
| Tolerance | 5 % |
| Operating Temperature | -55 to 125 °C |
| Lead Diameter | 0.508 mm |
| Max Processing Temp | 260 |
| Dielectric | C0G |
| MSL Level | 1 |
| Lead Finish | Matte Tin |
| Failure Rate | |
| Military Standard | |
| Termination Style | Radial |
| Product Depth | 3.175(Max) mm |
| Product Height | 5.08(Max) mm |
| Product Length | 5.08(Max) mm |
| Replacement Part Number | PART-SR217A151JAR |
| Weight | Contact us |
| Country of Origin | - |
