08055C102JAT2A AVX

08055C102JAT2A Images

Please contact us for more photos of 08055C102JAT2A

Part Number 08055C102JAT2A
Manufacturer AVX
Quantity in stock 181630 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Cap Ceramic 0.001uF 50V X7R 5% SMD 0805 125\u00b0C Paper T R
Category Capacitors
Family Capacitor Ceramic Multilayer
ROHS Compliant Yes
MSL Level 08055C102JAT2A
Datasheet download 08055C102JAT2A.pdf
Request Quotation for 08055C102JAT2A

08055C102JAT2A Specifications

Part Number 08055C102JAT2A
Dielectric X7R
Package/Case 0805
Voltage(DC) 50 V
Case Style Ceramic Chip
Construction Flat
Capacitance Value 0.001 uF
Rad Hard No
Operating Temperature -55 to 125 °C
Military Standard
Tolerance 5 %
Case Size 0805
Failure Rate
Product Dimensions 2.01 x 1.25 x 0.94 mm
Mounting Surface Mount
Max Processing Temp 260
MSL Level 1
Lead Finish Matte Tin
Product Depth 1.25 mm
Product Height 0.94(Max) mm
Product Length 2.01 mm
Replacement Part Number PART-08055C102JAT2A
Weight Contact us
Country of Origin -
