Please contact us for more photos of 08055A8R2BAT2A
| Part Number | 08055A8R2BAT2A |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 147350 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 8.2pF 50V C0G 0.1pF SMD 0805 125\u00b0C Paper T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | 08055A8R2BAT2A |
| Datasheet download |  08055A8R2BAT2A.pdf |
| Part Number | 08055A8R2BAT2A |
|---|---|
| Product Dimensions | 2.01 x 1.25 x 0.94 mm |
| Military Standard | |
| Rad Hard | No |
| Case Size | 0805 |
| Capacitance Value | 8.2 pF |
| Operating Temperature | -55 to 125 °C |
| Failure Rate | |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Dielectric | C0G |
| MSL Level | 1 |
| Lead Finish | Matte Tin |
| Tolerance | 0.1 pF |
| Package/Case | 0805 |
| Voltage(DC) | 50 V |
| Case Style | Ceramic Chip |
| Construction | Flat |
| Product Depth | 1.25 mm |
| Product Height | 0.94(Max) mm |
| Product Length | 2.01 mm |
| Replacement Part Number | PART-08055A8R2BAT2A |
| Weight | Contact us |
| Country of Origin | - |
