Please contact us for more photos of LGA10C-00SADJJ
| Part Number | LGA10C-00SADJJ |
|---|---|
| Manufacturer | Artesyn Embedded Technologies |
| Quantity in stock | 328730 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Module DC-DC 1-OUT 0.59V to 5.1V 10A 50W 24-Pin LGA |
| Category | Power Supplies |
| Family | DC to DC Power Supply |
| ROHS Compliant | Yes |
| MSL Level | LGA10C-00SADJJ |
| Datasheet download |  LGA10C-00SADJJ.pdf |
| Part Number | LGA10C-00SADJJ |
|---|---|
| Type | Non-Inverting|Inverting|Step Up|Step Down |
| Product Dimensions | 16.51 x 16.51 x 3.27 mm |
| Switching Regulator | Yes |
| Output Voltage | 0.59 to 5.1 V |
| Input Voltage | 3 to 14 V |
| Rad Hard | No |
| Supplier Package | LGA |
| Output Power | 50 W |
| Mounting | Surface Mount |
| Pin Count | 24 |
| Output Current | 10 A |
| Number of Outputs | 1 |
| Package | 24LGA |
| Replacement Part Number | PART-LGA10C-00SADJJ |
| Weight | Contact us |
| Country of Origin | - |
