Please contact us for more photos of CM6350R-224TR13
| Part Number | CM6350R-224TR13 |
|---|---|
| Manufacturer | API Delevan |
| Quantity in stock | 806080 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Choke Shielded Wirewound 220uH 25% 10KHz Ferrite 2.2A 9.14 X 9.14 X 5.08 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | CM6350R-224TR13 |
| Datasheet download |  CM6350R-224TR13.pdf |
| Part Number | CM6350R-224TR13 |
|---|---|
| Maximum DC Resistance | 0.027 Ohm |
| Type | Choke |
| Technology | Wirewound |
| Core Material | Ferrite |
| Test Frequency | 10 kHz |
| Rad Hard | No |
| Tolerance | 25 % |
| Package/Case | 9.14 X 9.14 X 5.08 |
| Operating Temperature | -55 to 105 °C |
| Inductance | 220 uH |
| Pin Count | 4 |
| Maximum DC Current | 2.2 A |
| Protection Style | Shielded |
| Package Dimensions | 9.14 x 9.14 x 5.08 mm |
| Product Depth | 9.14 mm |
| Product Height | 5.08 mm |
| Product Length | 9.14 mm |
| Replacement Part Number | PART-CM6350R-224TR13 |
| Weight | Contact us |
| Country of Origin | - |
