Please contact us for more photos of OQ08155100J0G
| Part Number | OQ08155100J0G |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 764710 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 8 POS 3.5mm Solder RA Thru-Hole Box |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | OQ08155100J0G |
| Datasheet download |  OQ08155100J0G.pdf |
| Part Number | OQ08155100J0G |
|---|---|
| Termination Method | Solder |
| Product Dimensions | 38.3 x 9.2 x 7.2 |
| Body Orientation | Right Angle |
| Mounting | Through Hole |
| Gender | HDR |
| Pin Count | 8 |
| Lead Finish | Tin |
| Contact Material | Brass |
| Contact Plating | Tin |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Operating Temperature | -40 to 115 °C |
| Housing Material | Thermoplastic |
| Housing Color | Green |
| Pitch | 3.5 mm |
| Product Depth | 9.2 mm |
| Product Height | 7.2 mm |
| Product Length | 38.3 mm |
| Replacement Part Number | PART-OQ08155100J0G |
| Weight | Contact us |
| Country of Origin | - |
