Part Number | HM2R87PA8108N9LF |
---|---|
Manufacturer | Amphenol-FCI |
Quantity in stock | 738880 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conn Hard Metric RCP 176 POS 4mm Press Fit RT Thru-Hole Tray |
Category | Connectors |
Family | Connector Backplane |
ROHS Compliant | Yes |
MSL Level | HM2R87PA8108N9LF |
Datasheet download | ![]() |
Part Number | HM2R87PA8108N9LF |
---|---|
Pin Count | 176 |
Termination Method | Press-Fit |
Maximum Voltage Rating | 750 Vac |
Number of Rows | 8 |
Gender | RCP |
Mounting | Through Hole |
Body Orientation | Right Angle |
Operating Temperature | -55 to 125 °C |
Maximum Contact Resistance | 20 MOhm |
Maximum Current Rating | 1.5 A |
Number of Contacts | 176 |
Type | Hard Metric |
Housing Material | Thermoplastic |
Pitch | 4 mm |
Rad Hard | No |
Contact Material | Copper Alloy |
Package Dimensions | 49.9 x 22.95 x 18.25 mm |
Product Depth | 22.95 mm |
Product Height | 18.25 mm |
Product Length | 49.9 mm |
Replacement Part Number | PART-HM2R87PA8108N9LF |
Weight | Contact us |
Country of Origin | - |
