D09P33E6GX00LF Amphenol-FCI

D09P33E6GX00LF Images

Please contact us for more photos of D09P33E6GX00LF

Part Number D09P33E6GX00LF
Manufacturer Amphenol-FCI
Quantity in stock 678480 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Conn D-Subminiature PIN 9 POS 2.74mm Solder RA Thru-Hole 9 Terminal 1 Port
Category Connectors
Family Connector D-Subminiature
ROHS Compliant Yes
MSL Level D09P33E6GX00LF
Datasheet download D09P33E6GX00LF.pdf
Request Quotation for D09P33E6GX00LF

D09P33E6GX00LF Specifications

Part Number D09P33E6GX00LF
Termination Method Solder
Lead Finish Matte Tin
Product Dimensions 30.81 x 18.5 x 12.58 mm
Mounting Through Hole
Body Orientation Right Angle
Operating Temperature -55 to 125 °C
Gender PIN
Contact Plating Gold Over Nickel
Rad Hard No
Pitch 2.74 mm
Product Depth 18.5 mm
Product Height 12.58 mm
Product Length 30.81 mm
Replacement Part Number PART-D09P33E6GX00LF
Weight Contact us
Country of Origin -
