Please contact us for more photos of 71600-006LF
| Part Number | 71600-006LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 391730 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn IDC Connector RCP 6 POS 2.54mm IDT RA Cable Mount Tube |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 71600-006LF |
| Datasheet download |  71600-006LF.pdf |
| Part Number | 71600-006LF |
|---|---|
| Maximum Current Rating | 1/Contact A |
| Maximum Contact Resistance | 15 mOhm |
| Termination Method | IDT |
| Body Orientation | Right Angle |
| Product Dimensions | 12.09 x 7.1 x 16.8 mm |
| Maximum Voltage Rating | 1000 Vac |
| Operating Temperature | -65 to 105 °C |
| Gender | RCP |
| Number of Contacts | |
| Housing Color | Gray |
| Pitch | 2.54 mm |
| Number of Rows | 2 |
| Type | IDC Connector |
| Rad Hard | No |
| Contact Plating | Gold Over Nickel |
| Mounting | Cable Mount |
| Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic |
| Product Depth | 7.1 mm |
| Product Height | 16.8 mm |
| Product Length | 12.09 mm |
| Replacement Part Number | PART-71600-006LF |
| Weight | Contact us |
| Country of Origin | - |
