Please contact us for more photos of 68602-472HLF
| Part Number | 68602-472HLF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 748440 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Unshrouded Header HDR 72 POS 2.54mm Solder ST Thru-Hole Poly Bag |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 68602-472HLF |
| Datasheet download |  68602-472HLF.pdf |
| Part Number | 68602-472HLF |
|---|---|
| Rad Hard | No |
| Max Processing Temp | 260 |
| Contact Material | Phosphor Bronze |
| Number of Rows | 2 |
| Product Dimensions | 91.44 x 4.83 x 8.38 mm |
| Contact Plating | Tin Over Nickel |
| Pitch | 2.54 mm |
| Maximum Current Rating | 3/Contact A |
| Type | Unshrouded Header |
| Lead Finish | Matte Tin |
| Termination Method | Solder |
| Maximum Voltage Rating | 1500 Vac |
| Body Orientation | Straight |
| Mounting | Through Hole |
| Gender | HDR |
| Housing Color | Black |
| Housing Material | Nylon|Polychlorinated Terphenyl|Liquid Crystal Polymer |
| Operating Temperature | -65 to 125 °C |
| MSL Level | 1 |
| Product Depth | 4.83 mm |
| Product Height | 8.38 mm |
| Product Length | 91.44 mm |
| Replacement Part Number | PART-68602-472HLF |
| Weight | Contact us |
| Country of Origin | - |
