Please contact us for more photos of 61083-121502LF
| Part Number | 61083-121502LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 858690 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board PL 120 POS 0.8mm Solder ST SMD T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 61083-121502LF |
| Datasheet download |  61083-121502LF.pdf |
| Part Number | 61083-121502LF |
|---|---|
| Lead Finish | Matte Tin |
| Termination Method | Solder |
| Mounting | Surface Mount |
| Pitch | 0.8 mm |
| Contact Material | Brass |
| Body Orientation | Straight |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 85 °C |
| Contact Plating | Gold Over Nickel |
| Housing Material | Liquid Crystal Polymer |
| Gender | PL |
| Product Dimensions | 53.8 x 6 x 4.7 mm |
| Product Depth | 6 mm |
| Product Height | 4.7 mm |
| Product Length | 53.8 mm |
| Replacement Part Number | PART-61083-121502LF |
| Weight | Contact us |
| Country of Origin | - |
