Please contact us for more photos of 61082-122402LF
| Part Number | 61082-122402LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 704020 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board RCP 120 POS 0.8mm Solder ST SMD T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 61082-122402LF |
| Datasheet download |  61082-122402LF.pdf |
| Part Number | 61082-122402LF |
|---|---|
| Rad Hard | No |
| Contact Plating | Gold Over Nickel |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Contact Material | Beryllium Copper |
| Housing Material | Liquid Crystal Polymer |
| Termination Method | Solder |
| Pitch | 0.8 mm |
| Gender | RCP |
| Lead Finish | Matte Tin |
| Body Orientation | Straight |
| Product Dimensions | 53.8 x 6.8 x 7.7 mm |
| Mounting | Surface Mount |
| Product Depth | 6.8 mm |
| Product Height | 7.7 mm |
| Product Length | 53.8 mm |
| Replacement Part Number | PART-61082-122402LF |
| Weight | Contact us |
| Country of Origin | - |
