Please contact us for more photos of 61082-082500LF
| Part Number | 61082-082500LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 681880 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | 545-5BYF-BRGSTK0.8 RECEPTACLE |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 61082-082500LF |
| Datasheet download |  61082-082500LF.pdf |
| Part Number | 61082-082500LF |
|---|---|
| Family | 61082 |
| Maximum Voltage Rating | 100 Vac |
| Contact Plating | Gold Over Nickel |
| Rad Hard | No |
| Number of Rows | 2 |
| Operating Temperature | -40 to 125 °C |
| Housing Material | Liquid Crystal Polymer |
| Mounting | Surface Mount |
| Termination Method | Solder |
| Packaging | Tube |
| Maximum Contact Resistance | 50 MOhm |
| Pitch | 0.8 mm |
| Type | Board to Board |
| Contact Material | Copper |
| Gender | RCP |
| Body Orientation | Straight |
| Number of Contacts | 80 |
| Lead Free | Yes |
| Maximum Current Rating | 0.8 A |
| Product Depth | 6.8 mm |
| Product Height | 7.7 mm |
| Product Length | 37.8 mm |
| Replacement Part Number | PART-61082-082500LF |
| Weight | Contact us |
| Country of Origin | - |
