Please contact us for more photos of 54202-G08-07LF
| Part Number | 54202-G08-07LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 483560 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Unshrouded Header HDR 14 POS 2.54mm Solder ST SMD Bag |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 54202-G08-07LF |
| Datasheet download |  54202-G08-07LF.pdf |
| Part Number | 54202-G08-07LF |
|---|---|
| Contact Plating | Gold Over Nickel |
| Pitch | 2.54 mm |
| Product Dimensions | 17.78 x 4.83 x 9.65 mm |
| Rad Hard | No |
| Contact Material | Phosphor Bronze |
| Max Processing Temp | 260 |
| Housing Material | Thermoplastic |
| Lead Finish | Matte Tin |
| Termination Method | Solder |
| Mounting | Surface Mount |
| Operating Temperature | -65 to 125 °C |
| Gender | HDR |
| Body Orientation | Straight |
| Housing Color | Black |
| Product Depth | 4.83 mm |
| Product Height | 9.65 mm |
| Product Length | 17.78 mm |
| Replacement Part Number | PART-54202-G08-07LF |
| Weight | Contact us |
| Country of Origin | - |
