Please contact us for more photos of 10034908-009LF
| Part Number | 10034908-009LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 897810 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Power Card Edge 26 POS 2.54mm Solder ST Edge Mount |
| Category | Connectors |
| Family | Connector Card Edge |
| ROHS Compliant | Yes |
| MSL Level | 10034908-009LF |
| Datasheet download |  10034908-009LF.pdf |
| Part Number | 10034908-009LF |
|---|---|
| Contact Material | Copper Alloy |
| Contact Plating | Gold Over Nickel |
| Mounting | Edge Mount |
| Pitch | 2.54 mm |
| Operating Temperature | -5 to 105 °C |
| Maximum Processing Temperature | 260 °C |
| Type | |
| Maximum Current Rating | |
| Number of Rows | |
| Maximum Contact Resistance | |
| Number of Contacts | |
| Card Thickness | |
| Maximum Voltage Rating | |
| Housing Material | Thermoplastic |
| Lead Finish | Matte Tin Over Nickel |
| Rad Hard | No |
| Termination Method | Solder |
| Pin Count | 26 |
| Housing Color | Black |
| Body Orientation | Straight |
| Product Height | 9.35 mm |
| Replacement Part Number | PART-10034908-009LF |
| Weight | Contact us |
| Country of Origin | - |
