Please contact us for more photos of N10226-52B2PC
| Part Number | N10226-52B2PC |
|---|---|
| Manufacturer | 3M |
| Quantity in stock | 730300 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn SCSI RCP 26 POS 2.54mm Solder RA Thru-Hole 26 Terminal 1 Port |
| Category | Connectors |
| Family | Connector SCSI |
| ROHS Compliant | Yes |
| MSL Level | N10226-52B2PC |
| Datasheet download |  N10226-52B2PC.pdf |
| Part Number | N10226-52B2PC |
|---|---|
| Housing Material | Zinc Alloy |
| Mounting | Through Hole |
| Contact Plating | Gold Over Nickel |
| Number of Ports | 1 |
| Lead Finish | Gold |
| Pitch | 2.54 mm |
| Product Dimensions | 37.2 x 16.7 x 9.4 mm |
| Gender | RCP |
| Type | SCSI |
| Max Processing Temp | 260 |
| Termination Method | Solder |
| Body Orientation | Right Angle |
| Contact Material | Copper Alloy |
| Operating Temperature | -55 to 105 °C |
| Product Depth | 16.7 mm |
| Product Height | 9.4 mm |
| Product Length | 37.2 mm |
| Replacement Part Number | PART-N10226-52B2PC |
| Weight | Contact us |
| Country of Origin | - |
